Roto NT Power Hinge - Page 51

Subject to change. Roto NT IMO_347_EN_v0
.
July 2014
.
51
Application range
Sash rebate width SRW ..........................600 – 1000 mm
Sash rebate height SRH ........................1600 – 2600 mm
Sash weight S.kg ........................................ max. 100 kg
Hardware overview
NT Designo (timber, PVC) – Turn-Only and Tilt&Turn hardware
Basic security
4 mm clearance
5
Corner drive 1 V 260272
5a
Corner drive, T&T 1 V 260288
8
Multipart centre lock, bottom horizontal
1)
SRW / mm SRH / mm Size Material no.
800 – 1000 200 1 V 296853
16
Packer 622615
14
Corner hinge 634705
17
Pivot rest, timber and PVC profiles,
axis 13 mm, rebate depth 24 mm
2)
L 563737
R 563736
Profile-related components
7
Tilt striker threshold set Eifel 13mm 534929
1) Not required with timber profiles.
2) With PVC profiles, observe the installation advice on page 80.
NOTE!
Resistant to driving rain when installed in
compliance with the system.
NOTE!
This document excerpt does not replace the
complete product documentation*. Non-com-
pliance exempts the hardware manufacturer of
his liability.
For all other Tilt&Turn hardware components
refer to:
 CTL_6_EN, CTL_7_EN
* Can be found on www.roto-frank.com
