Roto NT Power Hinge - Page 65

Subject to change. Roto NT IMO_347_EN_v0
.
July 2014
.
65
Product characteristics
Weather profile strip made of high-quality anodised
aluminium
End cap optically matched in design
Brush-seal mountings can be combined in five
different positions
51.5
32
4.5
24.4
9
Weather profile strip MD II
Description Length Surface-fi nish PQ Material no.
Weather profi le strip MD II 6 m E6 / C-0 60 m 604859
End cap for weather profile strip MD (pair)
Description Surface-fi nish PQ Material no.
End cap for weather profi le strip MD
incl. screw A24x20mm
Grey 50 P. 604868
PB 48 Fin-Seal brush seal
Description Surface-fi nish PQ Material no.
Brush seal, 10 mm Grey 60 m 601080
Brush seal, 17 mm Grey 40 m 604872
Dummy mullion seal for 2-sash doors on request.
Cut-off
connection element
Weather profi le strip MD II
Gealan S7000 IQ
Rehau Geneo
Trocal Innonova70.M5
Trocal Innonova 2000
Trocal Innonova Elegance
Weather profi le strip MD III
Aluplast Ideal 5000
Aluplast Ideal 6000
Aluplast Ideal 8000
Brügmann MD
Kömmerling 88+
Trocal 88+
51.5
32
4.5
24.4
11.5
Weather profile strip MD III
Description Length Surface-fi nish PQ Material no.
Weather profi le strip MD III 6 m E6 / C-0 60 m 604861
2
1
2
Parts list – Roto Eifel TB
Accessories
Weather profile strip MD
1
