RYTEC System 3 User Manual

20
SYSTEM STARTUP—PARAMETERS
P. 6 36 0 – 3 Up (
▲
) key traffic direction assignment
0: none
1: front-to-back
2: back-to-front
3: front-to-back and back-to-front
0
P. 6 40 0 – 2 Enter (
●
) key function
0: off
1: stop – door can be moved by any input command
2: stop – door can only be moved by keypad command
0
P. 6 50 0 – 2 Down (
▼
) key function
0: off in run mode – on in operator/service modes
1: on only in jog close
2: on in all functions
2
P. 6 55 0 – 1 Delay to open/close timer – activated with down (
▼
) key
0: off
1: on
1
P. 6 60 0 – 4 Floor loop detector – channel 1 function
0: off
1: open signal
2: safety – activating the loop with the door closing will reverse
the door; the door will remain open until the loop is inactive
and a timer or alternate action activator closes the door; the
loop is always inactive when the door is closed
3: safety – activating the loop with the door closing will reverse
the door; the door will remain open until the loop is inactive
and then immediately close once the loop becomes inactive;
the loop is always inactive when the door is closed
4: safety – activating the loop with the door closing will immedi-
ately stop the door; the door will remain stopped until the loop
is inactive and then immediately close when the loop becomes
inactive; the loop is inactive when the door is closed
1
P. 6 63 0 – 1 Open position – loop detector channel 1
0: full-open position
1: partial-open position
0
P. 6 64 0 – 2 Auto-close delay timers – loop detector channel 1
0: none
1: ACL1
2: ACL2
1
P. 6 65 0 – 1 Delay to open/close timer – loop detector channel 1
0: off
1: on
1
P. 6 66 0 – 3 Traffic direction assignment – loop detector channel 1
0: none
1: front-to-back
2: back-to-front
3: front-to-back and back-to-front
0
Parameter Range Service Level 2 Parameters Factory
Setting
