21
SYSTEM STARTUP—PARAMETERS
P. 6 67 0 – 1 Loop detector channel 1 disabled by:
0: loop detector channel 2
1: loop detector channel 2 and another activator
0
P. 6 68 0 – 120 seconds Time loop detector channel 1 is disabled by loop detector
channel 2 or another activator
0
P. 6 70 0 – 4 Floor loop detector – channel 2 function
0: off
1: open signal
2: safety – activating the loop with the door closing will reverse
the door; the door will remain open until the loop is inactive
and a timer or alternate action activator closes the door; the
loop is always inactive when the door is closed
3: safety – activating the loop with the door closing will reverse
the door; the door will remain open until the loop is inactive
and then immediately close once the loop becomes inactive;
the loop is always inactive when the door is closed
4: safety – activating the loop with the door closing will immedi-
ately stop the door; the door will remain stopped until the loop
is inactive and then immediately close when the loop becomes
inactive; the loop is inactive when the door is closed
1
P. 6 73 0 – 1 Open position – loop detector channel 2
0: full-open position
1: partial-open position
0
P. 6 74 0 – 2 Auto-close delay timers – loop detector channel 2
0: none
1: ACL1
2: ACL2
1
P. 6 75 0 – 1 Delay to open/close timer – loop detector channel 2
0: off
1: on
1
P. 6 76 0 – 3 Traffic direction assignment – loop detector channel 2
0: none
1: front-to-back
2: back-to-front
3: front-to-back and back-to-front
0
P. 6 77 0 – 1 Loop detector channel 2 disabled by:
0: loop detector channel 1
1: loop detector channel 1 and another activator
0
P. 6 78 0 – 120 seconds Time loop detector channel 2 is disabled by loop detector
channel 1 or another activator
0
Parameter Range Service Level 2 Parameters Factory
Setting
