RYTEC System 3 User Manual

24
SYSTEM STARTUP—PARAMETERS
The Following Parameters only apply to the Traffic Light Function
P.7x6 (This
parameter
determines
which relay
controls
which traffic
light.)
0 – 3 Relay Kx used for traffic light control
(P.7x0 set to “Traffic Light Function”)
0: green traffic light front
1: red traffic light front
2: green traffic light back
3: red traffic light back
0
P. 7 x7 0 – 1 Relay Kx switching behavior with door closed
0: off
1: on
2: flashing 1Hz
3: flashing 2Hz
x
P. 7 x8 0 – 2 Relay Kx switching behavior while door opens
0: off
1: on
2: flashing 1Hz
3: flashing 2Hz
x
P. 7 x9 0 – 2 Relay Kx switching behavior with door open
0: off
1: on
2: flashing 1Hz
3: flashing 2Hz
x
P. 7 xA 0 – 3 Relay Kx switching behavior during delay to close time
0: off
1: on
2: flashing 1Hz
3: flashing 2Hz
x
P. 7 xB 0 – 3 Relay Kx switching behavior while door is closing
0: off
1: on
2: flashing 1Hz
3: flashing 2Hz
x
P. 7 xC 0 – 3 Relay Kx switching behavior with door stopped between limits
0: off
1: on
2: flashing 1Hz
3: flashing 2Hz
x
P. 7 xD 0 – 3 Relay Kx switching behavior when the door is not ready for
automatic operation (e.g. during a failure or set-up mode)
0: off
1: on
2: flashing 1Hz
3: flashing 2Hz
Parameter Range Service Level 2 Parameters Factory
Setting
