R5 SOLID AIS System
TECHNINCAL SPECIFICATIONS
7000 118-200, C2 Page 54
6 TECHNINCAL SPECIFICATIONS
6.1 Physical
Dimensions:
Height: 87 mm
Width: 238 mm
Depth: 173 mm
Dimensions:
Incl. gimbal mount
Height: 124 mm (minimum)
Width: 292 mm
Depth: 173 mm
Weight:
2.25 kg
2.45 kg incl gimbalmount
6.2 Electrical
Input Voltage:
24 VDC
Power Consumption:
17 W (0.7 A @ 24 VDC input voltage)
6.3 Environmental
This product complies with the R&TTE directive, 1999/5/EC, as defined by the European
Parliament and Council.
Temperature:
-15˚C to +55˚C (Operational)
-30˚C to +80˚C (Storage)
Vibrations:
IEC 60945 ed. 4
EMC:
IEC 60945 ed. 4
Radio Type Approval:
IEC 61993-2 ed. 2
Compass Safe Distance
R5 SOLID
60 cm (for standard magnetic compass)
45 cm (for steering magnetic compass)
Compass Safe Distance
GPS Antenna AT575-68W
30 cm (for standard magnetic compass)
30 cm (for steering magnetic compass)
Compass Safe Distance
GPS Antenna MA-700
65 cm (for standard magnetic compass)
50 cm (for steering magnetic compass)
Compass Safe Distance
Combined VHF/GPS-1
65 cm (for standard magnetic compass)
50 cm (for steering magnetic compass)
