R5 SOLID AIS System
INTERPRETATION OF INPUT SENTENCES
7000 118-200, C2 Page 72
8.4 Long Range Input Sentences
8.4.1 On Long Range Port
The LR sentences can only be used with the Long Range interface port.
8.4.1.1 LRF AIS long-range function
$--LRF,x,xxxxxxxxx,cc,cc,cc
Field
Format
Name
Comment
1
--LRF
Sentence Id
Used
2
x
Sequence number
Used
3
xxxxxxx
xx
MMSI of requestor
Used
4
c--c
Name of requestor
Used
5
c--c
Function request
Used
6
c--c
Function reply status
Used
8.4.1.2 LRI AIS long-range interrogation
$--LRI,x,a,xxxxxxxxx,xxxxxxxxx,llll.ll,a,yyyyy.yy,a,llll.ll,a,yyyyy.yy,a
Field
Format
Name
Comment
1
--LRI
Sentence Id
Used
2
x
Sequence number
Used
3
xxxxxxx
xx
MMSI of requestor
Used
4
xxxxxxx
x
MMSI of destination
Used
5
llll.ll
Latitude
Used
6
a
N / S
Used
7
yyyyy.y
y
Longitude
Used
8
a
E / W
Used
8.4.2 On Other Input Ports
8.4.2.1 LRF AIS long-range function
$--LRF,x,xxxxxxxxx,cc,cc,cc
Field
Format
Name
Comment
1
--LRF
Sentence Id
Used
2
x
Sequence number
Used
3
xxxxxxx
xx
MMSI of requestor
Used
4
c--c
Name of requestor
Used
5
c--c
Function request
Used
6
c--c
Function reply status
Used
8.5 Proprietary Input Sentences
All Saab TransponderTech Proprietary Sentences will have talker ID PSTT.
8.5.1 Proprietary Query message PSTT,101
$PSTT,101,c--c,
Field
Format
Name
Comment
1
PSTT
Proprietary SAAB
TranspondeTech Sentence
Used
2
101
Sentence Query
Used
3
c--c
Proprietary sentence to query
Used
