Location of Engine-related Units
2-005
1. Intake hose
2. Air cleaner
3. Intake pipe
4. Intake hose
5. Intake hose
★ Above illustrations are the intake items of TW502.
1-3. Intake system
43
2
1
5
TW5022002
