Sakai TW352 - Steering Cylinder Assembly

2-050
Description and Operation of Hydraulic system
SW5002040
2
10
11
7
8
3
9
6
4
5
1
10
11
1. Cylinder
2. Piston rod
3. End cap
4. Piston
5. Nut
6. Seal
7. Dust seal
8. U-ring
9. O-ring
10. Spherical bearing
11. Lock ring
2-4-3. Steering cylinder assembly
