Sakai TW352 - Hydraulic Piping (Rear)

2-019
Description and Operation of Hydraulic System
2-2-2. Hydraulic piping (rear)
TW5022016
6
25 1 43
1. Rear propulsion motor
2. High pressure hose (forward travel)
3. High pressure hose (reversing)
4. Rear motor drain hose
5. Brake release hose
6. Bypass valve
★ Above illustrations represent the hydraulic piping of SW502.
