Brake System
3. Brake System
3-1. Brake pedal
TW5022047
A
A
4
3
1
2
5
SECTION A-A
1. Brake pedal
2. Brake pedal switch
3. F-R lever rod (centering rod)
4. F-R lever rod (centering rod)
5. Spring
