Sakai TW352 - SW352 Model Specifications

1-002
SPECIFICATIONS
1.External Views and Specification Data
1-1. SW352
1200
TW5021001
2000
2675
540
1200
1290
250
φ675
φ675
540
1580
NOTE: Gradability is the calculated value. It may vary with ground surface conditions.
Model SW352
Weight:
Gross weight
Empty weight
2,940 kg (6,485 lbs)
2,740 kg (6,045 lbs)
Dimension:
Overall length
Overall width
Overall height
Wheelbase
Wheel
Front
Rear
2,675 mm (105”)
1,290 mm ( 51”)
1,580 mm ( 62”)
2,000 mm ( 79”)
Roll (dia. x width)
675 x 1,200 mm (27” x 47”)
Roll (dia. x width)
675 x 1,200 mm (27” x 47”)
Performance:
Travel speed
(forward/reverse)
Low
High
0 ~ 9 km/h (0 ~ 5.6 mile/h)
0 ~ 12 km/h (0 ~ 7.5 mile/h)
Vibrating power:
Frequency
Centrifugal force
Gradability
Rolling width
Minimum turning radius
55 Hz
20.6 kN (4,630 lbs)
21 degrees
1,200 mm (47”)
3.8 m (150”)
Engine:
Model
Total displacement
Rated output
Max. torque
KUBOTA “D1503-KA” Diesel Engine
1.499 liters (91 cu.in)
20.1 kW/2,300 min
-1
(27 HP/2,300 min
-1
)
97 N·m/1,500 min
-1
(72 ft-lb/1,500 rpm)
Tank capacity:
Fuel tank
Hydraulic tank
Sprinkler tank
40 liters (10.6 gal)
43 liters (11.4 gal)
200 liters ( 53 gal)
