Sam4s ER-650 - RS232 C Port 1;RS232 C Port 2 Options

114 • Service Mode Programming ER-650/650R
RS232C Port 1/RS232C Port 2 Options
1. At the SM control lock position menu, press 8 for RS232C Port 1 programming
or 9 for RS232C Port 2 programming. The appropriate PORT PROGRAM
screen displays:
PORT 1 PROGRAM pg1
BAUD RATE 0
0: 9,600 1:1,200
2: 2,400 3:4,800
4:19,000
PARITY CHECK 0
0:NONE 1:ODD 2:EVEN
DATA BITS(0:8 1:7)0
2. At each field, press ENTER to view the selections. Enter the digit representing
your selection.
3. Press PAGE DOWN to view page 2 of the RS232C port program:
PORT 1 PROGRAM pg2
STOP BITS(0:1 1:2)0
DEVICE FUNCTION 0
--------------------
0:NONE 1:PC 2:SCL
3:RJ 4:RP 5:LT
6:SCAN 7:COIN 8:LIQ
9:POLE 10:EFT 11:PDC
4. Press PAGE DOWN to view page 3 of the RS232C port program:
PORT 1 PROGRAM pg3
INITIAL FEEDING LINE
ON KP(0-20) 0
ENDING FEEDING LINE
ON KP(0-20) 0
INITIAL FEEDING LINE
ON SLIP(0-20) 7
