5V
12V
Connect barcode scanner etc. to the serial port.
Connecting devices which uses the serial port
<Barcode Scanner>
Use RJ-11 port when Cash Drawer is desired & used
(Use SAM4S Cash Drawer).
Connecting RJ-11 Cash Drawer
<Cash Drawer>
PORT
5V 12V
(RS422/RS485)
COM1
○
COM3
X
COM4
X
○
○
○
○
○
