Sam4s SPT-3000 User Manual

1- 3
General Specification
Introductions
Unpacking
Specification
Product overview
HOME
Getting Started
Using this system
Removal and
Replacement
BIOS Setup
How to use PDF
e-manual
Exploded View
and Replaceable
parts
Dimension(mm)
387mm(W) × 278mm(L) × 340mm(H)
Di
mens
i
on
(
mm
)
38
7mm
(W)
×
2
7
8
mm
(L)
×
3
4
0
mm
(H)
Weight 5.8 Kg
CPU : Intel Atom Processor N270 1.6GHz(Onboard) Without FAN
P
FSB : 533MHz
Chip Sets
Northbridge : Intel 945GSE
Southbridge : Intel ICH7M
Processor
HDD 2.5" SATA Type
Serial(RS-232) Connector : D-SUB 9Pin x 3(COM1,3,4) + RJ45 Port x 1(COM5)
COM1,3,4,5 --> 5V or 12V Output(Main Board DIP Switch Setting)
I/O Interface
,,, p ( g)
Serial(RS-422/485) Connector : D-SUB 9Pin x 1(COM1 Common Use : BIOS Setting)
Parallel Connector : D-SUB 25Pin x 1
USB 2.0 Connector : Left Side x 1, Rear Side x 4
LAN Connector : RJ45 Port x 1(8Pin)
Cash Drawer Connector : RJ11 Port x 1(6Pin)
Cash
Drawer
Connector
:
RJ11
Port
x
1(6Pin)
VGA Connector : VGA Port x 1(15pin)
Audio Connector : Line out x 1, MIC x 1
OS
(Operating System)
Windows XP / 2000 / WEPOS / …
(Operating
System)
Main Memory DDR2 533/667/800 SO-DIMM Slot, (Up to 2GB)
Booting Device HDD, External CD/DVD-ROM Drive, USB Memory
Help Printer
Exit
Content

Sam4s SPT-3000 Specifications

General

Brand	Sam4s
Model	SPT-3000
Category	Touch terminals
Language	English
