Sam4s SPT-3000 User Manual

4-1
System Dismantle & Reassemble
Make sure the system & peripherals power are off.
1
Take off the connector cab from the bottom of system in case it is fixed with screws.
2
Disconnect cables for peripherals & DC power input jack from the system.
3
When disconnecting DC power supply
jack, the neck point should gently be
pulled out.
Please note!
