Sam4s SPT-3000 User Manual

4-19
Remove system back cover (refer to System Dismantle).
1
Disconnect cables as shown in the figure and undo screws.
2
※ It appears to happen defectives while disconnecting LCD and touch panel due to dust or mis-handling. Please get correct service from approved service center.
Warning!
Remove Touch panel
Help Printer
Exit
