Sam4s SPT-3000 User Manual

4-3
Stand can be dismantled as the figure shown.
8
Refer to the figure, unscrew, release lock lever and the system back
panel should be taken apart.
9
System dummy back panel can be dismantled
with the aid of figure.
10
