Sam4s SPT-3000 User Manual

4-2
CDP should be rotated as the direction shown in the figure
and press ‘PUSH’ area with hands.
4
CDP should be separated as the arrow shown and its connector
should be disconnected.
5
Lay the system while preventing LCD panel is being damaged.
6
Dismantle the stand, which is fixed with levers and it can be rotated.
