Sam4s SPT-3000 - Remove Dallas (Option)

4-23
Remove system back cover (refer to System Dismantle).
1
Disconnect cables which connect to its board.
2
Remove Dallas holder while rotating it in clock-wise.
3
Remove Dallas holder while rotating it in clock-wise.
4
1
2
Remove Dallas (Option)
