F Function WE Anl
Comment
Function block parameters / Range of values (default)
05 Underfloor heating
Drying of jointless
floors
0 All* CO2 -> F05 - 1: Limitation of the adjustment ranges
Function block parameters:
Start temperature / 20 to 60 °C (25 °C)
Temperature rise / 1 to 10 °C/24 h (5 °C/24 h)
Maximum temperature / 25 to 60 °C (45 °C)
Maintaining time of max. temperature/1 to 10 days (4 days)
Temperature reduction / 0 to 10 °C/ 24 h (0 °C / 24 h)
n
START,
nn
START,
nnn
START
06 Reserved
07 Optimization 0 All* CO2 -> F07 - 1: Only with • CO2 -> F01 - 1
• CO1 (2) -> F02 - 1
08 Adaptation 0 All* CO2 -> F08 - 1: Only with • CO2 -> F01 - 1
• CO1 (2) -> F02 - 1
• CO2 -> F11 - 0
09 Flash adaptation 0 All* CO2 -> F09 - 1: Only with CO2 -> F01 - 1
Function block parameter:
Cycle time / 1 to 100 min (20 min)
K
P
(gain) / 0 to 25 (0)
10 Reserved
11 4-point
characteristic
0 All* CO2 -> F11 - 1: 4-point characteristic,
only with CO2 -> F08 - 0
CO2 -> F11 - 0: Gradient characteristic
12 Control mode
three-step [Rk2]
0 to 10 V [Y2]
1 All* CO2 -> F12 - 1:With [Rk2] three-step control
With [Y2] 0 to 10 V control
Function block parameters:
K
P
(proportional gain) / 0.1 to 50.0 (2.0)
T
N
(reset time) / 1 to 999 sec (120 sec)
T
V
(derivative-action time) / 0 to 999 sec (0 sec)
T
Y
(valve transit time) / 5, 10, 15, ..., 240 sec (45 sec)
CO2 -> F12 - 0 (only in systems Anl 10.0, 10.1 and 10.3):
On/off control
Function block parameters:
Hysteresis / 1 to 30 °C (5 °C)
Min. ON time / 0 to 10 min (2 min)
Min. OFF time / 0 to 10 min (2 min)
13 Limit deviation for
OPEN signal
0 All* CO2 -> F13 - 1: Only with CO2 -> F12 - 1
Function block parameter:
Max. deviation / 2 to 10 °C (2 °C)
