F Function WE Anl
Comment
Function block parameters / Range of values (default)
14 Release Rk2
at BE16
0 All* CO2 -> F14 - 1: FG2 has no function
Select bE / 1, 0 (1)
F Function block number, WE Default value, Anl System code number
CO3: Heating circuit Rk3 (systems Anl 5.x, 6.0, 9.x, 12.x, 13.x, 21.x and 25.0)*
F Function WE Anl
Comment
Function block parameters / Range of values (default)
01 Room sensor RF3 0 All* CO3 -> F01 - 1: Temperature display and input FG3 for
Type 5244/5257-5 Room Panel active
TROVIS 5570 Room Panel:
CO3 -> F01 - 1 and CO7 -> F05 - 1
02 Outdoor sensor
AF2
0 5.x, 6.0,
9.5, 9.6,
13.x, 21.x
25.0
With measured value AF2, the value of AF1 is read
Outdoor temperature received via device bus:
CO3 -> F02 - 1 and CO7 -> F09 - 1
03 Return flow sensor
RüF3
1 21.x,
25.0
CO3 -> F03 - 1: Sensor and limiting function active
Function block parameter:
Limiting factor / 0.1 to 10.0 (1.0)
0 5.x, 6.0,
9.x, 12.x,
13.x
04 Reserved
05 Underfloor heating
Drying of jointless
floors
0 All* CO3 -> F05 - 1: Limitation of the adjustment ranges
Function block parameters:
Start temperature / 20 to 60 °C (25 °C)
Temperature rise / 1 to 10 °C/24 h (5 °C/24 h)
Maximum temperature / 25 to 60 °C (45 °C)
Maintaining time of max. temperature/1 to 10 days (4 days)
Temperature reduction / 0 to 10 °C/ 24 h (0 °C / 24 h)
n
START,
nn
START,
nnn
START
06 Reserved
07 Optimization 0 All* CO3 -> F07 - 1: Only with • CO3 -> F01 - 1
• CO1 (3) -> F02 - 1
08 Adaptation 0 All* CO3 -> F08 - 1: Only with • CO3 -> F01 - 1
• CO1 (3) -> F02 - 1
• CO3 -> F11 - 0
