F Function WE Anl
Comment
Function block parameters / Range of values (default)
17 Pump management
- switching state of
BA13
0 Not Anl
1.5-1.9,
3.5, 7.x
CO5 -> F17 - 1: Speed control released when BA13 = ON,
only when CO5 -> F07 - 0
CO5 -> F17 - 0: Speed control released when BA13 = OFF
18 BA9 replaced by
UP3
0 3.4, 4.2,
4.3, 10.2,
10.3
CO5 -> F18 - 1: The pump controlled by BA9 in the sche-
matics is controlled over UP3 output
19 Temperature
monitoring
0 All CO5 -> F19 - 1: Temperature monitoring active
20 Sensor calibration 1 All CO5 -> F20 - 1: Adjusting all sensor calibration values
CO5 -> F20 - 0: Deleting all adjusted sensor calibration
values
21 Locking manual
level
0 All CO5 -> F21 - 1: In switch position , automatic mode applies
22 Locking the rotary
switches
0 All CO5 -> F22 - 1: All rotary switches are locked
23 Outdoor tempera-
ture received over
0 to 10 V input
0 All CO5 -> F23 - 1: Outdoor temperature received over 0 to
10 V input
Function block parameters:
Lower transmission range / –30 to 100 °C (–20 °C)
Upper transmission range / –30 to 100 °C (50 °C)
*Not in Anl 1.0, 1.5, 1.6, 3.0, 4.0, 7.x, 10.x, 11.x, 12.x, 13.x, 21.x and 25.0
F Function block number, WE Default value, Anl System code number
CO6: Modbus, meter bus (all systems)
F Function WE Anl
Comment
Function block parameters / Range of values (default)
01 Modbus 1 All CO6 -> F01 - 1: Modbus active
02 Modbus 16-bit
addressing
0 All CO6 -> F02 - 1: 16-bit addressing, only with CO6 -> F01 - 1
CO6 -> F02 - 0: 8-bit addressing
03 Modem function 0 All CO6 -> F03 - 1: Only with CO6 -> F01 - 1 / F08 - 1
04 Automatic modem
configuration
0 All CO6 -> F04 - 1: Only with CO6 -> F03 - 1 / F08 - 1
05 Lock dial-up 0 All CO6 -> F05 - 1: No dial-up to GLT in case of error,
only with CO6 -> F03 - 1
EB 5579 EN 145
Appendix
