F Function WE Anl
Comment
Function block parameters / Range of values (default)
06 Dial-up also upon
corrected error
0 All CO6 -> F06 - 1: Dial-up to GLT also to indicate that an error
has been corrected, only with CO6 -> F03 - 1
07 Control system
monitoring
0 All CO6 -> F07 - 1: Resetting all level bits to “autonomous“
when there is no communication, only with CO6 -> F01 - 1
08 Text message 0 All CO6 -> F08 - 1: Sending of text message active
09 Reserved
10 Meter bus
(optional,
connection to ter-
minal 27, 28)
0 All CO6 -> F10 - 1: Meter bus active
Function block parameters: (for WMZ1 to WMZ3)
Meter bus address / 0 to 255 (255)
Model code / 1434, CAL3, APAtO, SLS (1434)
Reading mode / 24h, CONT, CoiL (24h)
For WMZ1 with “1434” and “CONT”, select:
tAr-A, tAr-E with time schedule
11 Flow rate limitation
in Rk1 using meter
bus
0 Not Anl
1.9
CO6 -> F11 - 1: Only with • CO6 -> F10 - 1
• CO5 -> F11 - 0
Function block parameters:
Max. limit value / 0.01 to 650
m
h
3
(1.5
m
h
3
)
Max. limit value for heating* / 0.01 to 650
m
h
3
(1.5
m
h
3
)
Max. limit value for DHW* / 0.01 to 650
m
h
3
(1.5
m
h
3
)
Limiting factor / 0.1 to 10 (1)
12 Capacity limitation
in Rk1 using meter
bus
0 Not Anl
1.9
CO6 -> F12 - 1: Only with • CO6 -> F10 - 1
• CO5 -> F10 - 0
Function block parameters:
Max. limit value / 0.1 to 6500 kW (1.5 kW)
Max. limit value for heating* / 0.1 to 6500 kW (1.5 kW)
Max. limit value for DHW* / 0.1 to 6500 kW (1.5 kW)
Limiting factor / 0.1 to 10 (1.0)
* Not in Anl 1.0, 1.5-1.8, 3.0, 4.0, 7.x, 10.x, 11.x, 12.x, 13.x 21.x and 25.0
F Function block number, WE Default value, Anl System code number
146 EB 5579 EN
Appendix
