Samson TROVIS 5579 - Page 147

CO7: Device bus (all systems, F02, F03, ... only with CO7 -> F01 -1)
F Function WE Anl
Comment
Function block parameters / Range of values (default)
01 Device bus 0 All CO7 -> F01 - 1: Device bus active
Function block parameter:
Device bus address /Auto*, 1 to 32 (32)
*Auto = controller automatically searches for free device bus
address in the system
02 Clock
synchronization
0 All CO7 -> F02 - 1: Controller sends its system time to all units
connected to the device bus every 24 hours
03 TROVIS 5570
Room Panel in Rk1
0 1.0–1.4,
2.x, 4.x,
6.0, 9.5,
9.6, 10.x,
11.x,
13.x,
21.x, 25.0
CO7 -> F03 - 1: Communication with TROVIS 5570 active
for Rk1; CO1 -> F01 - 1 is set automatically
Function block parameter:
Device bus address / Auto*, 1 to 32 (32)
*Auto = controller automatically searches for a room panel
for which detection mode has been activated
04 TROVIS 5570
Room Panel in Rk2
0 3.x, 4.x,
5.x, 6.0,
10.x,
25.0
CO7 -> F04 - 1: Communication with TROVIS 5570 active
for Rk2; CO2 -> F01 - 1 is set automatically
Function block parameter:
Device bus address / Auto*, 1 to 32 (32)
*Auto = controller automatically searches for a room panel
for which detection mode has been activated
05 TROVIS 5570
Room Panel in Rk3
0 5.x, 6.0,
9.x, 12.x,
13.x,
21.x, 25.0
CO7 -> F05 - 1: Communication with TROVIS 5570 active
for Rk3; CO3 -> F01 - 1 is set automatically
Function block parameter:
Device bus address / Auto*, 1 to 32 (32)
*Auto = controller automatically searches for a room panel
for which detection mode has been activated
06 Send value AF1 0 Not Anl
1.9
CO7 -> F06 - 1: Function block parameter:
Register no. / 1 to 4 (1)
07 Receive value AF1 0 Not Anl
1.9
CO7 -> F07 - 1: Function block parameter:
Register no. / 1 to 4 (1)
08 Send value AF2 0 Not Anl
1.9
CO7 -> F08 - 1: Function block parameter:
Register no. / 1 to 4 (2)
09 Receive value AF2 0 Not Anl
1.9
CO7 -> F09 - 1: Function block parameter:
Register no. / 1 to 4 (2)
EB 5579 EN 147
Appendix
