F Function WE Anl
Comment
Function block parameters / Range of values (default)
10 Send flow set point
Rk1
0 All CO7 -> F10 - 1: In systems Anl 1.5–1.8, 2.x, 3.1–3.4,
4.1–4.3, 7.x, 8.x, the storage tank charging set point is sent
during DHW heating
Function block parameter:
Register no./5to64(5)
11 Send flow set point
Rk2
0 All CO7 -> F11 - 1: Function block parameter:
Register no./5to64(5)
12 Send flow set point
Rk3
0 All CO7 -> F12 - 1: Function block parameter:
Register no./5to64(5)
13 Send flow set point
DHW
0 All CO7 -> F13 - 1: In level PA4, the Charging temperature
boost
parameter is generated
Function block parameter:
Register no./5to64(5)
14 Send maximum
flow set point
0 All CO7 -> F14 - 1: Internally, the controller already determines
the max. flow set point of its circuits and sends this value to
the primary controller;
Function block parameter:
Register no. / 5 to 64 (5)
15 Receive external
demand
0 Not Anl
1.9
CO7 -> F15 - 1: External processing of external demand in
Rk1 using device bus;
Function block parameter:
Register no./5to64 (5)
16 Display error
messages issued by
the device bus
0 All CO7 -> F16 - 1: Controller generates Err 5 message as long
as the errors of other device bus participants exist
17 Reserved
18 Reserved
19 Raise return flow
temperature limit
value
0 All CO7 -> F19 - 1: Return flow temperature limit value raised
of Rk1 when “DHW heating active“ message issued by de-
vice bus
Function block parameter:
Register no. / 5 to 64 (32)
20 Send “DHW
heating active“
0 All CO7 -> F20 - 1: Function block parameters:
Register no. / 5 to 64 (32)
21 Received release of
Rk1
0 All CO7 -> F21 - 1: Function block parameter:
Register no. / 5 to 64 (32)
