Solar pump OFF 0 to 30 °C
Max. storage tank temperature 20 to 90 °C
Function block parameters (CO4)
Level 4 Range of values
Limiting factor (F03 - 1) 0.1 to 10.0
Stop parallel operation in case of deviation (F06 - 1) 0 to 10 min
Flow limit temp. for parallel pump operation (F06 - 1) 20 to 90 °C
Activate priority in case of deviation (F08 - 1) 2 to 10 min
Correction factor (F08 - 1) 0.1 to 10.0
Activate priority in case of deviation (F09 - 1) 2 to 10 min
Proportional gain K
P
(F12 - 1) 0.1 to 50
Reset time T
N
(F12 - 1) 1 to 999 sec
Derivative-action time T
V
(F12 - 1) 0 to 999 sec
Valve transit time T
Y
(F12 - 1) 5 to 240 sec
Hysteresis (F12 - 0) 1 to 30 °C
Min. ON time (F12 - 0) 0 to 10 min
Min. OFF time (F12 - 0) 0 to 10 min
Max. deviation (F13 - 1) 2 to 10 °C
Day of the week (F14 - 1) 1–7, 1 to 7
Start time (F14 - 1) 0:00h to 23:45h
Stop time (F14 - 1) 0:00h to 23:45h
Disinfection temperature (F14 - 1) 60 to 90 °C
Set point boost (F14 - 1) 0 to 50 °C
Hold time of disinfection temperature (F14 - 1) 0 to 255 min
Parameters in level 5
Parameters (PA5) Level 5 Range of values
Public holidays
01.01
to 31.12
168 EB 5579 EN
Appendix
