Parameters (PA5) Level 5 Range of values
Vacation periods, start
01.01
to 31.12
Vacation periods, stop
Assignment to control circuit Rk1, Rk2, Rk3, Rk4
Vacation periods, start 01.01 to 31.12
Vacation periods, stop
Assignment to control circuit Rk1, Rk2, Rk3, Rk4
Function block parameters (CO5)
Start summer mode (F04 - 1) 01.01 to 31.12
No. of days until activation (F04 - 1) 1 to 3
Stop summer mode (F04 - 1) 01.01 to 31.12
No. of days until deactivation (F04 - 1) 1 to 3
OT limit value summer mode (F04 - 1) 0 to 30 °C
Delay (F05/6 - 1) 1 to 6 °C/h
Binary output bA (F07 - 1) 1, 0
Frost protection limit (F09 - 0 and F09 - 1) –15 to 3 °C
Max. limit value (F10 - 1) 3 to 500
pulse
h
Max. limit value for heating (F10 - 1) 3 to 500
pulse
h
Max. limit value for DHW (F10 - 1) 3 to 500
pulse
h
Limiting factor (F10 - 1) 0.1 to 10.0
Lower measuring range value (F11 - 1) 0/4 mA
Upper meas. range value 20 mA (F11 - 1) 0.01 to 650
m
h
3
Max. limit value (F11 - 1) 0.01 to 650
m
h
3
Max. limit value for heating (F11 - 1) 0.01 to 650
m
h
3
Max. limit value for DHW (F11 - 1) 0.01 to 650
m
h
3
Limiting factor (F11- 1) 0.1 to 10.0
Binary input bE (F12 - 1) 1, 0
Max. limit value (F13 - 1) 0.1 to 6500 kW
Max. limit value for heating (F13 - 1) 0.1 to 6500 kW
Max. limit value for DHW (F13 - 1) 0.1 to 6500 kW
Limiting factor (F13- 1) 0.1 to 10.0
EB 5579 EN 169
Appendix
