System Anl 11.2
System
Anl 11.2
With pre-control
Anl 11.2
Without pre-control
Type of DHW heating Type 2 Type 2
Integration of VF4, UP2 • –
ZP integration with CO4 ->
F10 - 1 (broken line, see cover)
Possible Possible
Note
–
VF2 takes the position of VF4
Default settings
CO1 -> F01 - 0 (without RF1)
CO1 -> F02 - 1 (with AF1)
CO1 -> F03 - 1 (with RüF1)
CO4 -> F01 - 1 (with SF1)
CO4 -> F02 - 1 (with SF2)
CO4 -> F03 - 0 (without RüF2)
CO4 -> F05 - 0 (without VF4)
EB 5579 EN 55
Systems
BE
BA
AE
AA
WW
KW
AF1
SF2
ZP SLPRüF1
VF1 VF4
RüF2UP1
SF1
RK1/Y1
RK2/Y2 RF1
UP2
VF2
