Samsung DVD-HD950 - Changing Setup Menu; HDMI Settings

ENG-67
Changing
Setup Menu
Black Level : Off
Sharpness : Level 3
Brightness : Level 3
Color Saturation : Level 3
Picture Quality
CHANGING
SETUP MENU
❻ HDMI
This setting is used when the unit is
connected by HDMI or DVI to Display
devices (TV, Projector, etc.).
- Resolution
•
480p/576p : 720 x 480, 720 x 576
• 720p : 1280 x 720
•
768p : 1024 x 768
• 1080i : 1920 x 1080
- Format
You can use this function to set HDMI or
DVI output's digital data RGB range.
• RGB-Normal : HDMI/DVI Limited range
RGB data output.
•
RGB-Expand : HDMI/DVI Full range RGB
data output.
• YCbCr-(4:4:4) : HDMI Limited range
YCbCr-(4:4:4) output.
•
YCbCr-(4:2:2) : HDMI Limited range
YCbCr-(4:2:2) output.
If you set the HDMI output resolution to
768p, you cannot use YCbCr format.
Limited range - Black/White and color level
displayed within Limited data range.
ex) When the bit depth is 8 bits
- Y : 16~235 - levels of brightness
- CbCr : 16~240 - levels of color
Ful range - Black/White and color level are
expressed within full data range.
ex) When the bit depth is 8 bits
- Y : 0~255 - levels of brightness
- CbCr : 0~255 - levels of color
- HD-JPEG
• HD : High Definition image source
- Available when resolution is
720p/768p/1080i in HDMI enabled.
• SD : Standard Definition image source
- DVI Output
You can use this function to set HDMI to
DVI output format.
•
This function corrects a TV screen when it
is not centered to secure a normal view.
• If HDMI to DVI Output is set incorrectly,
the screen can be biased.
❼ Picture Quality
- Black Level : Adjusts the brightness of the
screen.(On or Off) It does not function in
Progressive mode.
- Sharpness : Level 1 ~ Level 5
- Brightness : Level 1 ~ Level 5
- Color Saturation : Level 1 ~ Level 5
• Consult your TV User’s Manual to find
out if your TV supports Progressive Scan.
If Progressive Scan is supported, follow
the TV User’s Manual regarding
Progressive Scan settings in the TV’s
menu system.
• If Video Output is set incorrectly, the
screen may be blocked.
• The resolutions available for HDMI output
depend on the connected TV or projector.
For details, see the user’s manual of your
TV or projector.
• When the resolution is changed during
playback, it may take a few seconds for a
normal image to appear.
• If you set the HDMI output resolution 720p
or 1080i, HDMI output provides better
picture quality.
Resolution : 720p
Format : RGB-Normal
HD-JPEG : SD
HDMI
