Disassembly & Reassembly
Samsung Electronics 12-9
12-1-6 Ballast Replacement
Part Name Description Description Photo
Ballast
① Remove the lamp cover duct.
① Loosen 1point screw and pull out the lamp holder.
① Remove 2 screws.
① Remove the color wheel cover.
www.fieldtechsource.net
