Samsung HLS5087WX/XAA - IC Line up

Circuit Description
13-8 Samsung Electronics
13-3-5 IC Line Up
1. Main Board
2. Rear Board
3. Power Board
Items Descriptions Remarks
MPEG2 Decoder
(Albatross)
S5H2201X01 , Samsung
2 MPEG, 2 IPC, 3 Scaler, AC3-Decod, 32bit Graphic,
2 TS 1n, 1 TS out, 2ch 32bit DDR,
DDR SGRAM K4D551638F x 4 , Samsung 16Mx16bit (256Mbit)
One NAND Flash Memory KFG5616U1M , Samsung 16Mx16Bit (256Mbit)
SDRAM K4S561632E x 2 , Samsung 4Mx16x4Bit
Scaler SDP52 , Samsung MNR, CTI, AW, Pre-Processor, Main/Sub Scaler,JR
DDR SGRAM K4D263238F x 2 , Samsung 4x1Mx32Bit (128Mbit)
IPC Main SDP51 , Samsung Input Formats(INP),Super NE/NR(NRP),IPC
SDRAM K4S643232H x 2 32Mx4Bit (64Mbit)
Video Enhance SDP42 DNIe4
Analog Decoder, ADC_Sub SAA7119E , Philips Sub Tuner CVBS
TMDS Transmitter Sil7170 iTMDS Transmitter, 10bit
Micom S3F84BBXZZ, Samsung Micro Controller
Audio Processor STV8258DSX, ST Digital Audio Decoder
Sound AMP STA323W , ST Digital AMP
Items Descriptions Remarks
Video Switch TEA6425, SGS-Thomson Video Switch IC for TV * 2
Audio Switch TEA6422, SGS-Thomson Audio Switch IC for TV
HDMI Receiver & ADC MST3369M , Mstar
Digital Receiver for HDMI with HDCP(Component,HDMI,PC)
Analog Decoder,
ADC Main & 3D-Comb
TC90103AFG , Toshiba
Video Processor, ADC
(Video, S-Video, Main Tuner CVBS)
Items Descriptions Remarks
Main SMPS FS7M0880, Fairchild IC-PWM Controller ; Main Power
Stand-by SMPS [America] KA1M0565, Fairchild IC-PWM Controller ; Stand-by Power
