Samsung HLS5087WX/XAA - Engine Exploded View List

Reference Information
14-6 Samsung Electronics
K280 Engine Exploded View List
No. Description Specification Q'ty
1 ASSY LENS P-OPTIC MODULE NTR,xHD5 1
2 BRACKET-ENGINE BASE SVP-50L6HR,SECC,T1.6,XHD5 1
3 SHIELD CASE-DMD(F) SVP-50L6HR,SECC,T1.0 1
4 HODER-CLAMP DMD SVP-50L6HR,MG D/C,T2.5 1
5 DLP 1920x1080/xHD5,0.65,TYPE A 1
6 HODER-SOCKET DMD LCP,T3.0,BLACK,203PIN 1
7 ASSY PCB S-DMD GALILEI,K3,HLS6187,XHD5 1
8 BRACKET-PANEL SVP-50L6HR,AL D/C,T3.5 1
9 BRACKET-COOLER SVP-50L6HR,AL,T4.0 1
10 ASSY SHIELD P-PCB DLP ENGINE,SPTE,T0.5,DMD 1
11 BRACKET-FAN SVP-50L6HR,SECC,T1.0 1
12 FAN G6015M12B2-RG,K220,PBTP 1
13 COVER-P/J LENS SVP-50L6HR,ABS,T2.5,XHD5 1
14 RUBBER-COLOR WHEEL SVP-50L6HR,SILICON,NTR 1
15 GLASS-COLOR WHEEL 55mm,FLOAT GLASS,T0.7,AIR 1
16 HOLDER-COLORWHEEL SVP-50L6HR,MG D/C,T2.5,INSIDE 1
17 HOLDER-COLORWHEEL SVP-50L6HR,MG D/C,T2.5 1
18 GLASS-UV FILTER NA,GLASS,NTR,26x26,T1.1 1
19 BRACKET-UV FILTER SVP-50L6HR,SUS,T0.3 1
20 COVER-WHEEL K280,PC ABS,T2.5,BLK 1
21 LAMP-BALLAST EUC 132D P/41,132W,20KV 1
22 HODER-BALLAST K280,PC ABS,T2.5 1
23 COVER-DUCT TOP SVP-50L6HR,PC G/F20,T2.5,XHD5 1
24 RUBBER-FAN SVP-50L6,CR RUBBER,30,NTR,LAMP 2
25 FAN G9225L12B2-AG(WS),K220,PBTP 1
26 COVER-DUCT BOT SVP-50L6HR,PC G/F20,T2.5,XHD5 1
27 COVER-LAMP SVP-50L6HR,PPS G/F30,T2.5 1
28 ASSY MISC-THERMOSTAT HD5,125/250VAC 1
29 HODER-BALLAST PC G/F20,T2.5,SEKINOS 1
30 HODER-HOUSING LAMP SVP-50L6HR,AL D/C,T3.0 1
31 RUBBER-LAMP SVP-50L6HR,SILICON,NTR,BLACK 1
32 LAMP UHP 120W/132W 1.0,E22,65*70,LL 1
NUT-HEXAGON 2C,M4,ZPC(YEL),SM20C 1
WASHER-SPRING M4,ID4.1,0D7.6,T1.7,ZPC(YEL),S 1
HODER-SCREW LAMP B3K,PE,T0.5 1
HODER-LAMP SVP-50L6HR,PPS G/F30,T2.5 1
BRACKET-LAMP SVP-50L6HR,SUS,0.3,BOTTON 1
BRACKET-LAMP SVP-50L6HR,SUS,0.3,FRONT 1
COVER LAMP K280,PC G/F20,T3.0,xHD5 1
HANDLE-LAMP SVP-50L6HR,SUS,2.0 1
LABEL-00,LAMP A/P(90G),40,15,PHILIPS 132W 1
SCREW-TAPTITE PWH,+,B,M3,L10,ZPC(YEL) 1
SCREW-MACHINE WSP,PH,+,B,M4,L8,ZPC(YEL),SWRCH1 2
SCREW-TAPTITE PWH,+,B,M3,L10,ZPC(YEL) 1
33 COVER-DUCT RIGHT SVP-50L6HR,PC G/F20,T2.5,XHD5 1
34 HODER-DETECT S/W SVP-50L6HR,PC ABS,T2.5,BLK 1
35 SHEET-PAD S/W SVP-50L3,TIM,T0.5,NAT
