Wiring Diagram
8-2 Samsung Electronics
8-1-2 Connect Cables
Use Actuator_SP side AV 11P RMC 3p
Code BN39-00640C BP39-00096D BP39-00140E
Use RMC 2p key control 6p Power 24p
Code BN39-00656B BP39-00147B BP39-00174A
Use Ground discharge cable 1p Inlet SIDE AV 5P
Code BP39-00180C BP96-00972A BP39-00104D
Use Ballast cable key control 4p Main to DMD cable
Code BP39-00141A BP39-00103A BP39-00192A
※The code number of cable(Lead-connector) can be changed, see "5 Chapter. Electrical Part List."
