Alignment & Adjustment
3-20 Samsung Electronics
3-4 Service Adjustment
3-4-1 Vertical / Horizontal Position Adjustment
1. Turn off the power to put the unit into the STAND-BY mode.
2. In order to enter the Service Mode, Press "Mute" → "1" → "8" → "2" → "POWER" buttons on the Remote Control.
3. Select "Service" on the first display of the Service mode menu.
4. Select the V-position for vertical positioning and H-position for horizontal positioning by using the ▲▼(Up & Down) buttons.
Press the ◀▶ (Left or Right) buttons to adjust the screen position.
※ Do not set the V-position value to 34 or 35. (Setting to these values will cause horizontal lines on the right side of the screen.)
3-4-2 INDEX DELAY Adjustment
1. Turn off the power to put the unit into the STAND-BY mode.
2. In order to enter the Service Mode, Press "Mute" → "1" → "8" → "2" → "POWER" buttons on the Remote Control.
3. Select "Service" on the first display of the Service mode menu.
4. Press the ▲▼(Up or Down) button to move to INDEX DELAY, then press ENTER to select.
5. The INDEX DELAY setup screen (with White, Red, Green and Blue bars at the bottom of the screen) will be displayed.
6. Press the ◀▶ (Left of Right) buttons to adjust. Check the red color at the bottom of the screen at its minimum and maximum
values of changing from red to magenta, then adjust to the mean value.
