Circuit Description
Samsung Electronics 13-3
4. Input&Output voltage
1) Input voltage ＊ America(AC120V) - OPTION
＊ Korea(AC220V) - OPTION
＊ The others(AC100V~AC240V) - OPTION
2) Output voltage＊ D12V / 2.5A - 12V , 3.3V , 1.8V : For signal processing
＊ A6.5V / 1A - For driving the tuner
＊ S14.5V / 4A -For driving sound processor
＊ T30V / 5mA - For driving the tuner
＊ A65V / 30mA - For driving the actuator
