Alignment & Adjustment
Samsung Electronics 3-7
5. DNIe
No Item Range Default Remark
1 Test Pattern(DNIE) 0~25 0 Test pattern selection
2 SNI_PROC_CEA ON/OFF ON
3 SNI_PROC_CEP ON/OFF ON
4 SNI_PROC_DEP ON/OFF ON
5 SNI_PROC_DCE ON/OFF ON
6 SNI_PROC_CCS ON/OFF ON
7 SNI_PROC_BWS ON/OFF ON
8 SNI_PROC_PCC ON/OFF ON
9 SNI_PROC_WTE ON/OFF ON
10 SNI_PROC_CTE ON/OFF OFF
11 SNI_PROC_OUTP ON/OFF ON
12 B_RATIO 0~65535 13000 Low level information for the minimum value
13 W_RATIO 0~65535 6000 High level information for the minimum value
14 BLACK_TILT 0~255 90 Black Stretch Area
15 B_GAIN_MAX 0~225 358
16 WHITE_TILT 0~255 240 White Stretch Area
17 GAIN_X1 0~255 25 Gain of horizontal high frequency region
18 GAIN_X2 0~255 28 Gain of horizontal middle frequency region
19 GAIN_Y1 0~255 18 Gain of vertical high frequency region
20 GAIN_Y2 0~255 25 Gain of vertical middle frequency region
21 SUP_LIFT_SEL ON/OFF ON
22 EXT_SEL ON/OFF OFF
23 BOOL_SUPP_SELX1 ON/OFF OFF
24 BOOL_SUPP_SELX2 ON/OFF OFF
25 BOOL_SUPP_SELY1 ON/OFF ON
26 BOOL_SUPP_SELY2 ON/OFF OFF
27 BOOL_ENH_SEL ON/OFF OFF
28 LOG_MODE ON/OFF ON
29 R_MR 50~205 150
30 CORING_ON ON/OFF ON
31 RTH1 0~31 0
32 RTH2 0~31 12
33 NDON ON/OFF OFF
34 WB_RED_C_COEFF 0~255 128
35 WB_GRN_C_COEFF 0~255 128
36 WB_BLU_C_COEFF 0~255 128
37 WB_RED_B_COEFF 0~1023 512
38 WB_GRN_B_COEFF 0~1023 508
39 WB_BLU_B_COEFF 0~1023 512
