Alignment & Adjustment
Samsung Electronics 3-9
6. TC90103
No Item Range Default Remark
1 LIMYF 0~7 2 3D YNR limit level ; 000:small~111:large
2 KMFY 0~3 2
Feed back factor for 3D YNR ; 0£:x1:1/2,2:x3/4, 3:OFF
3 KFY 0~7 3 3D YNR Ga in; 000£ºOFF~111:x0.875
4 LIMCF 0~7 2
3D CNR limit level ; 000£ºsmall~111:large (INIT:110)
5 KMFC 0~3 2
Feed back factor for 3D CNR ;00:x 01:x1/2 10:x3/4 11:OFF
6 KFC 0~7 3 3D CNR Gain ;000:OFF~111x0.875
7 GVENH 0~3 1 Vertical enhance gain ;00:OFF 10:x1/4 01:x1/8 11:x1/2
8 VEN 0~3 3 Setup V enhance NL ;00: 6IRE 10:13IRE 01: 9IRE 1:16IRE
9 VEC 0~3 1
Setup corng level for V enhance ;00:OFF 10:1.6IRE 01:0.8IRE 11:2.3IRE
10 FENH 0~1 0 Sharpness fo ; 0:4.2MHz 1:3.3MHz
11 PRENH 0~1 0 Pre enhance 0:OFF 1:ON
12 GHENH 0~15 2 Adjustment Sharpness gain
13 NCLIM 0~7 0
Coring for sharpness/noise cancel ; 0:0.8IRE 1:3.2IRE 2:1.6IRE 3:6.4IRE
14 GNC 0~3 1 Setup gain for noise cancel ; 00:OFF 10:x1/2 01:x1/4 11:x1
15 GLTI 0~3 0 Setup L T I gain ;00:OFF 10:x1/4 01:x1/8 11:x1/2
16 LTILIM 0~3 0
Setup coring level for LTI ;00:0.8IRE 10:3.2IRE 01:1.6IRE 11:6.4IRE
17 SET DELAY 0~15 10
Chroma signal delay adjustment0000:-296ns~000:Center ~ 1111:259ns(37ns step)
18 GCTI 0~3 0 Setup CTI gain ; 00:OFF 10:x1/4 01:x1/8 11:x1/2
19 CTILIM 0~3 0
Setup coring level for CTI 00:0.4IRE 10;1.6IRE 01:0.8IRE 11:3.2IRE
20 FLTI 0~1 0 LTI fo 0:3.3MHz 1:2.2MHz OFF
21 FCTI 0~1 0 CTI fo 0:1.7MHz 1:3.4MHz
22 YCONT 0~255 66
Contrast adjustment 00h:x1/2~40h:x1~ FFh:x2.4
23 YBRIT 0~255 249
Brightness adjustment ;128:-128LSB:0 OFF~127:+127LSB(10b i t ) b i t
24 CRGAIN 0~15 0
C r signal gain adjustment ; 1000:x0~0000:x1~0111:x1.875
25 CBGAIN 0~15 1
C b signal gain adustment ;1000:x0~0000:x1 ~0111:x1.875
26 CROFS 0~15 1
C r signal offset adjustment at output stage 1000:-8LSB~0000:~ 0111:+7LSB(10bit)
27 CBOFS 0~15 1
C b signal offset adjustment at output stage 1000:-8LSB~0000:~ 0111:+7LSB(10bit)
28 HUE 0~127 0
Hue adjustmemt ;1000000:-45º~0000000:0º~0111111:+43 6º
29 HUE BIAS 0~63 0
Hue Bias adjustmemt ; 000000:0º~111111+45º
30 CKILL 0~7 7
Adjustment for the sensitivity of killer detect ratio ; 000:40dB~111:-30dB
31 BTCLON 0~1 1 LSB Process at SRC Block
32 BTCL ALT 0~1 0
33 YNRON - -
34 FILON 0~15 3
35 M_AGC_GAIN 0~225 33
36 3D/2D 2D/3D 3D
37 SNR - 117[0x75]
