Alignment & Adjustment
Samsung Electronics 3-15
11. SDP52
No Item Range Default Remark
1 DIFF_MODE 0 0 Select a differential filter
2 WS_EIGENLPF 0~31 4
3 BLEND_ALPHA 0~255 0
4 BLEND_BETA 0~511 0
5 Main YH_SHOOT 0~1 1
6 Main CH_SHOOT 0~1 1
7 Main PC_MODE 0~1 0 Shoot Control or Median Filter
8
Main YH_SHOOT_PARA1
0~255 32 Clipping Gain Parameter
9 Main YH_SC_ALPHA 0~31 31
10 Main YH_SLOPE 0~255 64 Small Ringing Control
11
Main AUTO_PAGE_SEL
0~1 0 Filter Page Select
12 Main YH_PAGE 0~31 1
13 Main YV_PAGE 0~31 5
14 Main CH_PAGE 0~31 16
15 Main CV_PAGE 0~31 16
16 Sub YH_SHOOT 0~1 1
17 Sub CH_SHOOT 0~1 1
18 Sub PC_MODE 0~1 0 Shoot Control or Median Filter
19
Sub YH_SHOOT_PARA1
0~255 32 Clipping Gain Parameter
20 Sub YH_SC_ALPHA 0~31 31
21 Sub YH_SLOPE 0~255 64 Small Ringing Control
22 GAINU 0~1023 64 CB CTI gain
23 GAINV 0~1023 64 CR CTI gain
24 R_CHCNT_ON 0~1 1
25 H_TRUNC 0~63 32
26 H_INT_GAIN1 0~127 4
27 H_INT_GAIN2 0~127 4
28 V_INT_GAIN 0~63 4
29 V_TRUNC 0~63 32
30 PRE_ALPHA 0~127 4
31 PRE_BETA 0~63 5
32 DE_GAIN_X1 0~255 16
33 DE_GAIN_X2 0~255 24
34 DE_GAIN_Y1 0~255 40
35 DE_MR 0~255 50
36 H_RTH2 0~31 10
37 V_RTH2 0~31 10
38 DE_H_CORING_F1 0~31 4
