Samsung HLS5087WX/XAA User Manual

PCB Diagram
9-2 Samsung Electronics
9-1-3 Power Board Connector Pin
CN804
Connecting Power to Main Board
Pin Name PIN No. Pin Name
STD5V 1 2 N.C
GND 3 4 S14.5V
STD5V 5 6 S_GND
GND 7 8 S14.5VB
POWER_SW 9 10 S_GND
5.7VB 11 12 5.7VB
GND 13 14 GND
12V_OPTION 15 16 12V_OPTION
GND 17 18 GND
12VB 19 20 12VB
GND 21 22 GND
GND 23 24 12VB
