PCB Diagram
Samsung Electronics 9-9
CN1700
PIN No. Pin Name PIN No. Pin Name PIN No. Pin Name
1 MONITOR_R_OUT 33 NRESETO_D 65 M_TU_CVBS
2 MONITOR_L_OUT 34 NRSTO_IN 66 NC
3 GND 35 NC 67 DTV_CVBS
4 NC 36 MST_INT 68 GND
5 NC 37 MST_RESET 69 AV2_DET
6 NC 38 NC 70 AV1-DET
7 GND 39 GND 71 COMP2_DET
8 HDMI2_ID 40 S2_DET 72 COMP1_DET
9 HDMI1_ID 41 S1_DET 73 PCJACK_ID
10 M_HS 42 SDA 74 MAIN_VBIR
11 M_VS 43 SCL 75 M_DE
12 M_PCLK 44 GND 76 GND
13 GND 45 M_ROUT(6) 77 M_ROUT(2)
14 M_ROUT(9) 46 M_ROUT(5) 78 M_ROUT(1)
15 M_ROUT(8) 47 M_ROUT(4) 79 M_ROUT(0)
16 M_ROUT(7) 48 M_ROUT(3) 80 GND
17 GND 49 GND 81 M_GOUT(3)
18 M_GOUT(9) 50 M_GOUT(6) 82 M_GOUT(2)
19 M_GOUT(8) 51 M_GOUT(5) 83 M_GOUT(1)
20 M_GOUT(7) 52 M_GOUT(4) 84 M_GOUT(0)
21 GND 53 GND 85 GND
22 M_BOUT(9) 54 M_BOUT(5) 86 M_BOUT(2)
23 M_BOUT(8) 55 M_BOUT(4) 87 M_BOUT(1)
24 M_BOUT(7) 56 M_BOUT(3) 89 M_BOUT(0)
25 M_BOUT(6) 57 GND 89 GND
26 GND 58 SIDE_R 90 GND
27 GND 59 SIDE_L 91 GND
28 GND 60 MAIN_R 92 GND
29 GND 61 MAIN_L 93 GND
30 GND 62 I2S_RX_MCLK 94 GND
31 I2S_RX_BCLK 63 I2S_RX_LRCLK 95 RX_RS232
32 I2S_RX_DATA 64
SUB_WOOFER_OUT
96 TX_RS232
To Next Page
