2.
Product
Specications
and
Description
Motor
and
Clutch
location
[
5
]
[
1
]
[
2
]
[
3
]
[
4
]
[
6
]
[
7
]
[
8
]
[
9
]
[
1
0
]
1
Main
Motor
6
Duplex
Clutch
2
OPC
Motor
7
Registration
Clutch
3
Exit
Motor
8
Cassette
Pick
up
Clutch
4
T
oner
Supply
Motor
9
MP
Pick
up
Clutch
5
Knock-Up
elevating
motor
10
Envelope
pressure
clutch
Fan
Location
[
3
]
[
1
]
[
2
]
1
Main
Fan
2
LSU
Fan
3
SMPS
Fan
Copyright©
1995-2016
SAMSUNG.
All
rights
reserved.
2-40
50
52
