Appendix
A
-1
Appendix A
Factory setting that change with the motor capacity
C2.01
Motor
terminal
resistance
(Ω )
C2.02
Motor
iron
loss
(Watt)
C2.03
Motor
rated
current
(A)
C2.04
Motor
no load
current
(A)
C2.05
Motor
rated
slip
(Hz)
20P4 10.50 25 2.40 1.40 3.83
20P7 7.50 30 3.80 2.20 3.66
21P5 2.60 75 6.60 4.30 3.00
22P2 1.80 90 9.00 4.40 2.67
23P7 0.90 200 14.30 7.00 2.33
40P4 26.00 30 1.40 0.90 3.83
40P7 18.00 45 2.20 1.30 3.66
41P5 9.70 83 3.80 2.20 3.00
42P2 4.60 150 5.20 2.50 2.67
43P7 3.00 230 8.30 4.00 2.33
A-2 MOSCON-E7 User’s Manual
Appendix B
Monitors
Name Unit Display Page
U0.01 Effective Frequency Command 0.01Hz xx.xx~xxx.x 5-4
U0.02 Current Output Frequency 0.01Hz xx.xx~xxx.x 5-4
U0.03 Output Current in RMS 0.01A xx.xA 5-4
U0.04 Output Voltage in RMS 1V xxxu 5-4
U0.05 DC link Voltage 1V dxxx 5-4
U0.06 Output Power in 0.1kW 0.1kW Pxx.x 5-4
U0.07 Motor speed in RPM 1rpm xxxx 5-4
U0.08 Percentage Output Torque 1% oxxx 5-4
U0.09 I/O Status bit 5-4
U0.10 Cumulative Power On Time 10Hr xxxx 5-4
U0.11 Elapsed Time since Power On min.sec mm.ss 5-4
U0.12 S/W Version r.xxx 5-4
Last Fault
Name Unit Display Page
U1.01 Command Frequency 0.01Hz
xx.xx~xxx.x
5-5
U1.02 Output Frequency 0.01Hz
xx.xx~xxx.x
5-5
U1.03 Output Current 0.01A xx.xA
5-5
U1.04 Output Voltage 1V xxxu
5-5
U1.05 DC Voltage 1V dxxx
5-5
U1.06 Output Power 0.1kW Pxx.x
5-5
U1.07 Motor rpm 1rpm xxxx
5-5
U1.08 Output Torque 1% oxxx
5-5
U1.09 I/O Status bit
5-5
U1.10 Cumulative Power On Time 10Hr xxxx
5-5
Fault List
Name Unit Display Page
U2.01 Fault 1 (recent) - *
5-5
U2.02 Fault 2 - *
5-5
U2.03 Fault 3 - *
5-5
U2.04 Fault 4 - *
5-5
