Appendix
A
-3
Parameter Check List
Name Unit Display Page
U3.01 Modified Parameter List - “----” (None)
5-5
U3.02 Fault Parameter List - “----” (None)
5-5
B-parameter
Basic Setup
Name Unit
Setting
Range
Factory
Setting
Changeable
During Operation
Page
B0.01
Active Source of
Frequency Command
- 00~23 00 X
5-10
B0.02
Active Source of
RUN Command
- 00~12 00 X
5-10
B0.03 Stopping Method - 0~1 0 X
5-11
B0.04
Prohibiting
Reverse Rotation
- 0~1 0 X
5-11
B0.05
Default Motor
Direction
- 0~1 0 O
5-12
B0.06 Default Monitor Item - 1~10 0 O
5-12
B0.07
Automatic Start after
Power On
- 0~1 0 O
5-12
System Initialization
Name Unit
Setting
Range
Factory
Setting
Changeable
During Operation
Page
B1.01
Inverter
Initialization
- 0~9999 0000 X 5-13
B1.02 Check Password - 0~9999 0000 X 5-14
B1.03 Set Password - 0~9999 0000 X 5-14
System Capacity Setup
Name Unit
Setting
Range
Factory
Setting
Changeable
During Operation
Page
B2.01
Power Capacity of
the Inverter
- 20P4~43P
7
- X 5-14
B2.02
Power Capacity of
the Motor
- 20P4~43P
7
- X 5-14
A-4 MOSCON-E7 User’s Manual
F-parameter
Frequency/Speed Command
Name Unit
Setting
Range
Factory
Setting
Changeable
During operation
Page
F0.01
Main Frequency
Command of
Operator Mode
&
Communication
Mode
0.01Hz 0.00~600.00 0.00 ○ 5-15
F0.02 Frequency2 0.01Hz 0.00~600.00 0.00 ○ 5-15
F0.03 Frequency3 0.01Hz 0.00~600.00 0.00 ○ 5-15
F0.04 Frequency4 0.01Hz 0.00~600.00 0.00 ○ 5-15
F0.05 Frequency5 0.01Hz 0.00~600.00 0.00 ○ 5-15
F0.06 Frequency6 0.01Hz 0.00~600.00 0.00 ○ 5-15
F0.07 Frequency7 0.01Hz 0.00~600.00 0.00 ○ 5-15
F0.08 Frequency8 0.01Hz 0.00~600.00 0.00 ○ 5-15
F0.09 Jog Frequency 0.01Hz 0.00~600.00 6.00 ○ 5-15
Frequency Limit
Name Unit
Setting
Range
Factory
Setting
Changeable
During Operation
Page
F1.01 High Speed Limit 0.1% 0.1~100.0 100.0 ○ 5-16
F1.02
L
ow Speed Limit 0.1% 0.0~99.9 0.0 ○ 5-16
Jump Frequency Limit
Name Unit
Setting
Range
Factory
Setting
Changeable
During Operation
Page
F1.03 Jump Frequency1 0.01Hz 0.00~600.00 0.00 ○ 5-16
F1.04 Jump Frequency2 0.01Hz 0.00~600.00 0.00 ○ 5-16
F1.05 Jump Frequency3 0.01Hz 0.00~600.00 0.00 ○ 5-16
F1.06
Jump Frequency
Width
0.01Hz 0.00~20.00 0.50 ○ 5-16
F1.07 Jump Mode - 0~1 0 X 5-17
Frequency Detection
Name Unit
Setting
Range
Factory
Setting
Changeable
During Operation
Page
F1.08
Frequency of
Match Detection
0.01Hz 0.00~600.00 0.00 ○ 5-19
F1.09
Frequency Match
Detection Width
0.01Hz 0.00~20.00 0.50 ○ 5-19
F1.10
Frequency of
Accel/Decel
Time Switching
0.01Hz 0.00~600.00 0.00 ○ 5-19
