Tunable Semiconductor Laser TSL-770
5-9
4.
The setting items are as follows:
Sweep Setting (1/3)

λ
start
Sets the sweep start wavelength
  Range:Wavelengthrangesspeciedinthespecications
Unit: 0.0001 nm

λ
stop
Sets the sweep end wavelength
  Range:Wavelengthrangesspeciedinthespecications
Unit: 0.0001 nm

Pwr
Sets the optical power during sweep
Range: 20dB up to peak power
Unit : 0.01dB (0.01mW)
If the setting value is more than the maximum power, “PWR Err” is displayed to issue
an alarm that the actual output power is deviated from the setting value.
In the maximum power mode, power setting is not available and monitor power is
displayed.
NOTE
