TSL-770 Operation Manual
■
7-2-1. Connection
Connect USB B type cable to the connector leveled “USB DEVICE” on rear panel. “USB
HOST” connector is not used for communication.
7- 2 USB
USB (Device)
■
7-2-2.
Communication Conditions and System Requirements
USB 2.0 compatible
Transfer speed: 1 MBps (with D2XX driver)
Transfer speed: 300 KBps (with VCP driver)
Transfer FIFO size
Sending FIFO：384 bytes
Receiving FIFO: 128 bytes
Setting the Delimiter: The delimiter of the command is “CR”.
At receiving time, the reception of commands is completed and analysis begins
after the delimiter is recognized. At sending time, the delimiter is added to the
end of the response string and then sent.
