Santec TSL-770 - Communication Conditions and System Requirements; Settings

7-14
TSL-770 Operation Manual
■
7-3-2.
Communication Conditions and System Requirements
Electrical Specications: IEEE802.3 Standard
Transfer Method: Ethernet (100BASE-TX)
Transfer speed: 100Mbps
Communication Protocol: TCP/IP
Connector Type: RJ-45IP
IP Address: *.*.*.* (* = integer from 0 ~ 255)
Subnet mask: *.*.*.* (* = integer from 0 ~ 255)
Default Gateway: *.*.*.* (* = integer from 0 ~ 255)
DHCP Option Support Port No. : Integer from 0 ~ 65535
The delimiter of the command is “CR+LF”.
The command is accepted and analysis begins when the delimiter is received. At
sending time, the delimiter is added to the end of the response string and sent.
■
7-3-3.
Settings
1. Touch MENU , NEXT , COM , and LAN . Ethernet setting screen is displayed.
