From these motors and amplifiers, the following 17 systems can be assembled. All the
systems can operate up to 4,500 RPM (except for the P6 motor that is 3000 RPM). The
power listed is continuous at 3,000 RPM (except for the P6 motor at 2000 RPM) while
the torque listed is continuous at 0 RPM.
Table 2: Valid Drive Systems
PY2 Amplifiers PY0 Amplifiers Motor Model W Nm
15A 30A 50A 15A 30A 50A 100A 150A
P30B04010D 100 0.35
~
~
P30B06040D 400 1.37
~
~
P30B08075D 750 2.55
~
~
P20B10150D 1500 4.9
~
~
P20B10250D 2500 8.8
~
P20B13300D 3000 10.8
~
P20B13500D 5000 18.1
~
P50N05020D 200 0.686
~
~
P50N08100D 1000 3.92
~
~
P60B13150H 1500 7.5
~
~
The remote operator or PY software is required to set/change all the parameters in the
traditional PY amplifiers.
The remote operator is not required for operation and may therefore be shared between
all the drives in a system. The same remote operator is used for the PY amplifiers.
The PC-SETUP software can be used to set/change all parameters in the traditional PY
amplifiers (except for power phasing). This item may be purchased instead of the remote
operator.
Systems
Remote Operator /
Software
