Applicable Wire Sizes
The chart below identifies the recommended wire sizes for all connections. This is only a
guide. The installer is responsible for satisfying all applicable codes and regulations.
DANGER
!
The user is responsible for conforming with all applicable local, regional,
national, and international codes. The wiring examples in this manual are
intended only as a guide. Wiring practices, grounding, disconnects and over-
current protection are of particular importance. Failure to observe this could
result in severe injury or loss of life.
Table 8: Applicable Wire Sizes
Terminal PY2A015
PY0A015
PY2A030
PY0A030
PY2A050
PY0A050
PY0A100 PY0A150
Bus Power R, S, T 16 14 12 10 8
Control Power r, t 16
Motor Power U, V,
W
16 14 12 10 8
Regen Resistor
Power
Thermostat
Y, COM
(P)
H1, H2
16
20
14
20
Drive Ready
Relay
RDY1,
RDY2
20
Encoder CN2 28
Control (CN1) CN1 28
Remote Operator OP
1. Wire sizes are AWG.
2. To avoid electrical interference, separate the bus circuit wiring (high voltage) from
the signal wiring (CN1, CN2).
