Sanyo PLC-WU3800 Service Manual

-49-
Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
23 (SUB) V Back Porch 85 0 - 4095
25 (SUB)Clamp 80 0 - 4095
26 (SUB)Clamp Width 31 0 - 4095
Group
527
YCbCr (1080i - 50)
0 Total Dots 2640 0 - 4095 * Read only
1 Disp Dots 1872 0 - 4095
2 H Back Porch 259 0 - 4095
3 V Back Porch 49 0 - 4095
4 Disp Line 1052 0 - 4095
5 Clamp 150 0 - 4095
6 Clamp Width 31 0 - 4095
22 (SUB) H Back Porch 225 0 - 4095
23 (SUB) V Back Porch 83 0 - 4095
25 (SUB)Clamp 80 0 - 4095
26 (SUB)Clamp Width 31 0 - 4095
Group
528
YCbCr (1035i)
0 Total Dots 2200 0 - 4095 * Read only
1 Disp Dots 1874 0 - 4095
2 H Back Porch 259 0 - 4095
3 V Back Porch 90 0 - 4095
4 Disp Line 1006 0 - 4095
5 Clamp 140 0 - 4095
6 Clamp Width 31 0 - 4095
22 (SUB) H Back Porch 225 0 - 4095
23 (SUB) V Back Porch 125 0 - 4095
25 (SUB)Clamp 80 0 - 4095
26 (SUB)Clamp Width 31 0 - 4095
Group
540
RGB Video (480i)
0 Total Dots 1716 0 - 4095
1 Disp Dots 1346 0 - 4095
2 H Back Porch 174 0 - 4095
3 V Back Porch 48 0 - 4095
4 Disp Line 460 0 - 4095
5 Clamp 460 0 - 4095
6 Clamp Width 1 0 - 4095
22 (SUB) H Back Porch 292 0 - 4095
23 (SUB) V Back Porch 45 0 - 4095
25 (SUB)Clamp 160 0 - 4095
26 (SUB)Clamp Width 31 0 - 4095
Group
541
RGB Video (575i)
0 Total Dots 1728 0 - 4095
1 Disp Dots 1318 0 - 4095
2 H Back Porch 208 0 - 4095
3 V Back Porch 64 0 - 4095
4 Disp Line 536 0 - 4095
5 Clamp 1 0 - 4095
6 Clamp Width 31 0 - 4095
22 (SUB)H Back Porch 328 0 - 4095
23 (SUB)V Back Porch 62 0 - 4095
25 (SUB) Clamp 180 0 - 4095
26 (SUB)Clamp Width 31 0 - 4095
Group
542
RGB Video (480P)
0 Total Dots 1716 0 - 4095
1 Disp Dots 1368 0 - 4095
2 H Back Porch 163 0 - 4095
3 V Back Porch 50 0 - 4095
4 Disp Line 458 0 - 4095
5 Clamp 1 0 - 4095
6 Clamp Width 31 0 - 4095
22 (SUB)H Back Porch 278 0 - 4095

Sanyo PLC-WU3800 Specifications

General

Matrix size	0.59 \
Projection distance	0.99 - 12.1 m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	40 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	±40 °
Audio input	2
Aspect ratio	16:10
Network ready	Yes
Power supply type	AC
Dimensions (WxDxH)	335.7 x 257.5 x 93.6 mm
Connectivity technology	Wired
Focus	Manual
Digital zoom	16 x
Focal length range	19.2 - 30.2 mm
Noise level	35 dB
Noise level (economic mode)	31 dB
Dot clock scanning frequency	140 MHz
Lamp type	NSHA
Lamp power	275 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	3000 h
DVI port	No
Composite video in	-
Serial interface type	RS-232
USB 2.0 ports quantity	0
Supported video modes	1080i, 1080p, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	White
AC input voltage	100 - 240 V
Power consumption (standby)	0.7 W
Power consumption (typical)	317 W
Power consumption (PowerSave)	280 W
Cables included	VGA

Weight and Dimensions

Depth	257.5 mm
Width	335.7 mm
Height	93.6 mm
Weight	3500 g
